Product Summary
PN4392 is Symmetrical silicon n-channel,PN4392 in plastic TO-92 envelopes. PN4392 intended for
applications such as analog switches,choppers, commutators etc.
Parametrics
(1)Drain-source voltage 闁?VDS max.40V;
(2)Total power dissipation
up to Tamb =25 闁硅櫣鐓癙tot
Drain current
VDS = 20V; VGS =0 IDSS
Gate-source cut-off voltage
VDS = 20V; ID =1 nA -VGS off
Drain-source on-resistance
D = 1 mA; VGS =0 RDS on
max. 360 mW
PN4391 PN4392 PN4393
min.50 25 5mA;
min.4 2 0.5V;
max.10 5 3V;
max.30 60 100
Features
Symmetrical silicon n-channel
junction FETs in plastic TO-92
envelopes. They are intended for
applications such as analog switches,
choppers, commutators etc.
PINNING
Note: Drain and source are
interchangeable.
1=gate
2=source
3=drain
Diagrams
